Signal Transformer / Bel F1F1 Shielded SMT Inductors

Signal Transformer / Bel F1F1 Shielded SMT Inductors are high-power inductors designed to meet the rigorous standards of the AEC-Q200 Grade 1 automotive quality certification. These inductors feature high performance (I_sat) realized by metal dust core and low loss realized with low DCR. The F1F1 inductors are available in 0.47μH to 33μH inductance range with 20% tolerance and offer low DCR ranging from 4.2mΩ to 200mΩ. These inductors operate at -55°C to 155°C temperature range and comply with Moisture Sensitivity Level-1 (MSL-1). The F1F1 inductors are ideal for automotive, industrial, and high-power electronic systems that demand robust and efficient inductive components.
