ADS5295PFP

Name: Texas Instruments ADS5295PFP
Brand: Texas Instruments
SKU: 595-ADS5295PFP
Price: 146.96 EUR
Availability: InStock

Images are for reference only
See Product Specifications

Mouser No:

595-ADS5295PFP

Mfr. No:

ADS5295PFP

Mfr.:

Texas Instruments

Datasheet:

ECAD Model:

Download the free Library Loader to convert this file for your ECAD Tool. Learn more about the ECAD Model.

Stock:: 25 Can Dispatch Immediately

An unexpected error occurred. Please try again later.
Factory Lead Time:: 18 Weeks Estimated factory production time for quantities greater than shown.

Enter Quantity:

Minimum: 1 Multiples: 1

Unit Price:

-,-- €

Ext. Price:

-,-- €

Est. Tariff:

This Product Ships FREE

Mfr. Part No.:

Packaging:

Reel, Cut Tape, MouseReel

Availability:

In Stock

Price:

121,78 €

Min:

Mfr.:

Texas Instruments

Mfr. No:

ADS5295PFPR

Description:

Analog to Digital Converters - ADC Octal CH 12B 100MSPS Hi-SNR & Lo-Pwr ADC A 595-ADS5295PFP

Compare With Current Part

.hidden-for-nojs { display: none; } .pull-right-nojs { justify-content: flex-end; }

Product Attribute	Attribute Value	Select Attribute
Manufacturer:	Texas Instruments
Product Category:	Analog to Digital Converters - ADC
RoHS:
Series:	ADS5295
Mounting Style:	SMD/SMT
Package/Case:	HTQFP-80
Resolution:	12 bit
Number of Channels:	8 Channel
Interface Type:	SPI
Sampling Rate:	100 MS/s
Input Type:	Differential
Architecture:	Pipeline
Analogue Supply Voltage:	1.8 V
Digital Supply Voltage:	1.8 V
SNR - Signal to Noise Ratio:	70.6 dB
Minimum Operating Temperature:	- 40 C
Maximum Operating Temperature:	+ 85 C
Packaging:	Tray
Brand:	Texas Instruments
Country of Assembly:	Not Available
Country of Diffusion:	Not Available
Country of Origin:	PH
Development Kit:	ADS5295EVM
DNL - Differential Nonlinearity:	+/- 0.82 LSB
ENOB - Effective Number of Bits:	11.4 Bit
Features:	High Performance
Moisture Sensitive:	Yes
Number of Converters:	1 Converter
Output Type:	LVDS
Power Consumption:	640 mW
Product Type:	ADCs - Analog to Digital Converters
SFDR - Spurious Free Dynamic Range:	86 dB
SINAD - Signal to Noise and Distortion Ratio:	70.4 dB
Factory Pack Quantity:	96
Subcategory:	Data Converter ICs
Supply Voltage - Max:	1.9 V
Supply Voltage - Min:	1.7 V
Unit Weight:	378,600 mg
